Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box
Description
104 30A** 4x4 shift motor & clutch
105 40A** Climate control front blower
106 20A** Intercooler pump (supercharged
engine only)
107 — Not used
108 30A** Trailer tow electric brake
109 — Not used
110 30A** Accessory delay relay (Not used
on SuperCrew)
111 40A** Ignition switch battery feed (start
and run circuits)
112 30A** Drivers power seat, Adjustable
pedal switch
113 40A** Ignition switch battery feed (run
and accessory circuits)
114 — Not used
115 20A** Power door locks (SuperCrew
only)
116 — Not used
117 — Not used
118 30A** Heated seats
201 — Trailer tow park lamp relay
202 — Front wiper run/park relay
203 — Trailer tow backup lamp relay
204 — A/C clutch relay
205 — Horn relay
206 — Fog lamp relay
207 — Front washer pump relay
208 — Intercooler pump relay
(supercharged engine only)
209 — Front wiper HI/LO relay
301 — Fuel pump relay
Roadside Emergencies
212
