Parts Diagram
D
1. Vehicle Body
2. Dashboard
3. Windshield
4. Hubcap - 4
5. Driver - 2
6. Front Axle - 2
7. Steering Linkage
8. Wheel - 4
9. Rear Axle
10. Hood
11. Hood Latch - 2
12. Brush Guard
13. Steering Column
14. Steering Wheel
15 Steering Wheel Cap
16. Roll Bar
17. Seat
18. Washer - 4
19. .437 Cap Nut - 8
20. Short Bushing - 2
21. Super 6 ™ Volt Charger
22. 6 Volt Battery
23. Asembly Tool
24. Long Bushing - 2
25. Spacer - 2
Not Shown
#10 x 1" Screw - 8
#8 x 4" Screw - 2
#8 x 1" Screw - 2
Label Sheet - 2
5
2
21
3
16
15
22
19
19
19
19
19
19
17
13
6
12
7
8
8
1
24
20
24
14
18
18
18
9
19
20
18
6
4
4
4
10
11
11
25
25
23
Hint: Some parts shown are assembled on both sides of the vehicle.
