Colour monitor 19P2
14 - English A26361-K713-Z100-1-5E19
Setting picture size ( Size )
! " = Making the picture narrower or wider
$ # = Making the picture shorter or longer
Setting full-screen display ( Zoom )
! " = Increasing or reducing the size of the screen display
Setting the picture geometry
Trapezoid distortion is when the top or bottom of the screen display is too wide or too narrow.
Parallelogram distortion means that the sides of the picture bend to the left or right. Tilt distortion
must be set when the screen display is not axially symmetrical. Unsymmetrical pin balance is when
the sides of the screen displays are bent inward or outward on one side. Vertical linearity must be
set when the screen display appears distorted at the top or bottom.
Calling the Geometry setting window
Correcting parallelogram and tilt distortion ( Parallel/Rotation )
! " = Reducing the angle of the left and right sides
$ # = Rotating the picture in a clockwise or counter-clockwise direction
) (
Correcting pincushion and trapezoid distortion ( Pincushion/Trapezoid )
! " = Bending the right and left side inward or outward
$ # = Making the bottom edge narrower and the top edge wider or making the top
edge narrower and the bottom edge wider
Correcting unsymmetrical pincushion distortion ( Pinbalance )
! " = Setting the sides so that they are symmetrical
Adjusting the vertical linearity ( Linearity )
! " = Correcting compression distortion at the top or bottom of the display
Adjusting the colours
RGB
Setting colour temperature ( Color )
The "warmth" of the screen colours is set using the colour temperature. The
monitor has three fixed colour temperatures (K = Kelvin).
Color 1 = 9300 K (factory setting)
Color 2 = 6500 K (factory setting)
Color 3 = 5000 K (factory setting)
You can adjust the colour temperature in 100-K steps in the range from 5000 K to
9300 K (
! " ) or select ( $ # ) and adjust the proportion of red, green and blue as
required ( ! " ).
