12. Specifications S220
Size 39cm cube, with 2cm high feet/round edges
Weight 26 kilograms
Type Front firing closed box tissue cover
Anechoic Frequency Response 25 Hz to 200Hz, ±3 dB
In-Room Frequency Response Typically 20 Hz to 200 Hz, ±3 dB
THD Less than 3% THD at 94 dB SPL from 30 Hz and up
Maximum Output 112dB SPL in room
Amplifier Type Class T with linear power supply
Volume Adjustment >60 dB of range
Crossover Frequency 60 Hz to 200 Hz
Crossover Type 4
nd
order Butterworth (24 dB/octave)
Subsonic Filter Variable room gain compensation
Phase Adjustment Variable between 0 to 180 degrees + inverting switch
Power Output 220W RMS
High pass filter for the panels Switchable (1,2,3) for 300i, 400i, 600i and 1000i Final
panels
Low Level Input Impedance 20 kΩ
High Level Input Impedance 1 kΩ
Driver 12 inch long throw driver
Approval ETL UL Can CE CB
