Assembly – Fisher-Price CAMP BARBIE 74780 User Manual
Page 13

13
Hood
Grille
• Raise the hood.
• Fit the tabs at the bottom of the grille into the slots in the
vehicle body.
• Press near the top of the grille to snap it into the vehicle
body.
16
Radiator
Sheet
Grille
Vehicle
Body
• Slide the radiator sheet behind the grille.
• Lower the hood.
17
• Fit the tab on one side of a headlight lens into the notch
in the grille.
• Push firmly to snap the tab on the other side of the lens
into the grille.
• Repeat this procedure to assemble the other headlight
lens.
Headlight
Lens
Tab
18
• With the ends of the sport bar angled toward you, fit the
half of the sport bar cover marked “BAC” under the sport
bar.
• Align the holes in the sport bar with the holes in the
sport bar cover half.
• Insert two #6 x 1
1
/
2
" screws up through the sport bar
cover half and through the sport bar.
19
Half of
Sport Bar
Cover
(BAC)
Sport Bar
Holes
Assembly
