3-10
OWN SHIP INFO menu
Open the OWN SHIP INFO menu by choosing 5 OWN SHIP INFO from the INITIALIZE menu.
OWN SHIP INFO menu
LENGTH/WIDTH, SCANNER POSN and SUB SCANNER POSN
To accurately inscribe own ship marker on the screen, enter length and width of the ship and
scanner position from the bow and left sides, for both main and sub scanners. The setting ranges
are as follows:
LENGTH: 0 to 999 m
WIDTH:
0 to 999 m
BOW: 0 to 999 m
LEFT: 0 to 999 m
GPS 1 ANT POSN and GPS 2 ANT POSN
This is for AIS. Enter the GPS antenna position, from the bow and left side. The setting ranges are
the same as above.
CONNING POSN
Enter the conning position, from the bow and left side. The setting ranges are the same as those
shown on the preceding page. When you set the reference point as the conning position, these
values are used to correct the radar antenna position.
Note: If two or more radars are installed, all items on the OWN SHIP INFO menu should be the
same except 3 SCANNER.
[OWNSHIP INFO]
1 BACK
2 LENGTH/WIDTH
LENGTH 100 m
WIDTH 50 m
3 SCANNER POSN
BOW 0 m
PORT 0 m
4 SUB SCANNER POSN
BOW 0 m
PORT 0 m
5 GPS1 ANT POSN
BOW 0 m
PORT 0 m
6 GPS2 ANT POSN
BOW 0 m
LEFT 0 m
7 CONNING POSN
