Fedders Split System Air Conditioner - Manual (Page 7)

6
24 AB 1 VF D C
18 = 18000 BTU/H [5.28 kW]
24 = 24000 BTU/H [7.03 kW]
30 = 30000 BTU/H [8.79 kW]
36 = 36000 BTU/H [10.55 kW]
42 = 42000 BTU/H [12.31 kW]
48 = 48000 BTU/H [14.07 kW]
60 = 60000 BTU/H [17.5 kW]
1 = 208/230 Volts, 1 Phase, 60 Hz
2 = 230 Volts, 1 Phase, 50 Hz
3 = 208/230 Volts, 3 Phase, 60 Hz
4 = 460 Volts, 3 Phase, 60 Hz
5 = 230 Volts, 3 Phase, 50 Hz
6 = 380 Volts, 3 Phase, 50 Hz
C = Air Conditoner
CH = Heat Pump
A
F= Fedders
Poduct Type
Brand
V = Sweat
Fitting Type
D = R-22 Refrigerant
Z = R-410A Refrigerant
Variations
Electrical Designation
B = 21 1/2” W x 21 1/2” D x H
C = 29 1/2” W x 29 1/2” D x H
Chassis Size
Nominal Capacity
Series
CONDENSING UNIT
NOMENCLATURE
