To remove the tonneau cover:
The tonneau cover needs to be
supported during removal. This is a
two person operation.
• Remove the cargo divider, refer
to To remove the cargo divider
on the previous page.
• Disconnect the hydraulic
cylinders from the pickup box
and secure them in the clips on
the tonneau cover. Close the front panel.
• Open and support the front panel.
• Stow the rear panel on top of the front panel, refer to To stow the
rear panel shown previously.
• Pull two release levers on the underside of the tonneau cover from the
pickup box and remove the tonneau cover.
For installation of the tonneau cover, reverse the removal procedure.
