2. WIRING
2-9
Location of connectors
Open the processor unit as follows and the 03P9342 board appears.
J621
J620
J619
J618
J612
J610
J608
J607
J606
J605
J604
J603
J602
J601
J617
J616
PSU
J654
J615
J614
J613
Tx HV line
J609
Cable clamp
03P9342
Gyro converter board
or AD-100
Speed log
Navigator
Heading sensor
Cable from control unit
PC
Cable from antenna unit
Coaxial wire
Gyro converter board
AIS
External alarm
Track control
ECDIS
Sub display*
Master radar
+ 12 V for card I/F
Sub display*
(SEMI-LOG)
(FULL-LOG)
J611
Cable from Power
supply unit
03P9342
*: See page 2-11 for details.
