Specifications
Input / Output Array
Fujitsu General America, Inc. • 353 Route 46 West • Fairfield, NJ 07004
Tel: (888) 888-3424 Local: (973) 575-0380 • Fax: (973) 836-0448
w w w . p l a s m a v i s i o n . c o m
Model P65FT00AUB
Screen Size (Diagonal) 65” diagonal
Screen Dimensions (WxH) in. 56-7/16 x 31-3/4
Dimensions (WxHxD) in. 62-11/16 x 38-3/16 x 3-15/16*
Weight (lbs) 167.6
Pixel Count 1920 x 1080
TV Standards Supported NTSC, ATSC
Video Inputs
Video x 1, HDMI x 2, S-terminal x 1,
Component x 2
RGB Mode VGA, WVGA, SVGA, XGA, WXGA, SXGA
Component Video Mode SDTV 480i, 480p / HDTV 720p, 1080i
Computer Inputs RGB 15-pin x 1
Antenna Input F-type connector x 2 (1 terrestrial, 1 cable)
Built-In Speaker Output Max. output: 12W + 12W, 4 ohm
Audio Inputs RCA terminal (L/R) x 3 sets, 0.5 Vrms
Audio Output Optical Digital, Stereo R C A Type Analog
Power Source 110 - 240 V, AC 50/60 Hz
Language (OSD) English, Spanish, French
Included Accessories User’s manuals, 1 power cable, 1 remote control
Optional Accessories
Wall Bracket
Black Desk Stand P-65AVI-B
P-TT6500-B
Copyright © Fujitsu General America, Inc., 2007. AVIAMO is a registered trademark of Fujitsu General Limited.
CableCARD™ is a trademark of Cable Television Laboratories, Inc..
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.
The DCR logo is a registered trademark of the Consumer Electronics Association and Cable Television Laboratories, Inc.
In the U.S., TV Guide and other related marks are registered marks of Gemstar-TV Guide International, Inc. and/or one of its affiliates
Control
RS232
6 5
HDMI
Video In
RGB 1
15 pin D sub Digital
TV AUDIO
out CableCARD
AUDIO
in
3
2
1
1394
Link (2)
Video In
4 3 2
Component
S-vid
Compos.
1
RF
CATV
Antenna
A/C
110v-240v
Speaker
out
Digital Video Processing
The system has been specifically enhanced for 1080p scaling,
processing and display. The result is exquisitely detailed picture quality
and natural color display.
• AVM Noise Reduction So much of today's video contents have
flaws, also known as artifacts, marring the resulting images.
identifies and corrects these flaws to deliver clear, satisfying big-screen
pictures.
• Advanced Color Management Digitally enhances primary hues so
they appear more natural and vivid.
• Ambient Light Sensor Senses the relative brightness of the room
and digitally adjusts the screen brightness and contrast to create the
perfect viewing environment.
• Automatic Edge Correction identifies the edges of image
elements, and applies edge correction to clarify the elements' boundaries
so they look clear, crisp and natural.
HDMI Connectivity
All AVIAMO Displays feature two High Definition Multimedia
Interface (HDMI) inputs, enabling true high-definition audio/video
content and crystal-clear digital quality through a single cable.
Built-in DCR™ Tuner & CableCARD™ Slot
Experience digital cable and HDTV without a separate set top box.
View hi-definition programming in a clutter-free environment by using
the built-in CableCARD™ slot.
Advanced IEEE 1394 Connection
Provides additional input flexibility and access to HD content.
Designed to Perfection
As envisioned by renowned Japanese artist and designer Shigeru
Uchida, Fujitsu's AVIAMO display line is an elegant departure from
conventional flat-panel display designs. Most striking is the rich piano-
black bezel and sharp angled features of the display itself.
TV GUIDE
The TV Guide On Screen ® interactive program guide lets you sort
through programs and channels, locate high-definition broadcasts, set
reminders and record your favorite shows - all with a touch of the
remote control.
Warranty
Enjoy peace of mind with Fujitsu’s exclusive 3-year warranty that
covers Parts, Labor
and the Display Panel Glass Element. * This is the depth of the main set cabinet. A small input housing adds 2-3/16" for a total depth of 6-1/8". This housing does not
effect mounting depth when using the optional Fujitsu P-65AVI-B accessory wall bracket.
Specifications are subject to change without notice for further improvement. Please go to www.plasmavision.com to view the latest
specifications, accessory information and the full AVIAMO line-up.
