PARTS C
Key Assembly
Assembly Tool
2 Short Seat Belts
H0440pr-0923
Long Seat Belt
12 Volt Battery
12 Volt Charger
Fasteners Shown Actual Size
For your convenience, we included extra fasteners!
Note: Tighten and loosen all screws with a Phillips screwdriver.
Do not over-tighten the screws.
#8 x 3 /
4
" Screw – 37
7 /
16
" Washer – 2 3 /
8
" -16 Lock Nut – 2
5 /
32
x 1 1 /
2
" Pin – 1
1 /
4
x 1 1 /
4
" Screw – 2
