Plan the Interface
PN: 1725-36134-001_E.doc 9
The system administrator may use the Extension Assignments
Worksheet at the end of this document to track the port numbers,
extensions, users, and features assigned to handsets.
The Wireless Telephone Display
The SpectraLink Wireless Telephone will display the telephone
number as it is dialed.
The DT14DS has a two-line by 20-character display. The handset
display is 2 lines by 16 characters; therefore, some F9600 messages
may be truncated when displayed on the handset.
Certain characters may be used by the system that are not
implemented in the handset. Flashing characters are not implemented
on the handset, nor is rolling or scrolling of text.
Although some desksets do not have a display, any display
information sent by the system will be displayed on the handset.
Handset indicators
Line indicators are associated with line access keys. Status indicators
or icons are associated with voicemail, low battery function, other
functions, and service interruption. A left or right arrow is displayed
when the screen can be toggled either left or right to display more
characters.
When lines are programmed as shown on the key-map diagrams, the
numeral icons on the handset display will be mapped to any deskset
LEDs associated with the corresponding feature keys. The line icons
will be displayed as follows:
Line State Handset Line Status Icon State
On-hook Off
Off-hook On
Ringing Fast flash
On hold Slow flash
