Copyright 2009 Firstech, LLC. Page 27
CM6000 Install Guide
Alarm and Starter System
www.firstechonline.com | www.compustar.com
4-01 Aux 1 Output - This option determines the duration of the auxiliary 1 output. Setting IV allows the out
put duration to be set for a specific length of time.
4-02 Aux 2 Output - This option determines the duration of the auxiliary 2 output. Setting IV allows the out
put duration to be set for a specific length of time.
4-03 Aux 1 Output Control - This option controls the way auxiliary 1 is controlled at different events.
4-04 Aux 2 Output Control - This option controls the way auxiliary 2 is controlled at different events.
4-05 Secure Aux Output – On the default setting, button 4 on the remote must be pressed first before Aux 1
or Aux 2 can be triggered. This prevents accidental triggering of the outputs. Option setting II turns this
feature off.
4-06 Aux 1 Input – This option changes the input behavior of the pre-warn wire on the Aux Input Sensor
green connector.
Default 1: Will pre-warn with a negative (-) ground input.
Option 2: Will instant trigger with a negative (-) ground input.
Option 3: Will disarm the alarm with a negative (-) ground input. Used when adding an alarm to a
factory keyless entry system.
Option 4: Will disarm the alarm with a positive (+) 12V input. Used when adding an alarm to a factory
keyless entry system.
4-07 Aux 2 Input – This option changes the input behavior of the instant trigger wire on the Aux Input Sensor
green connector.
Default 1:. Will instant trigger with a negative (-) ground input.
Option 2: Will pre-warn with a negative (-) ground input.
Option 3: Will arm the alarm with a negative (-) ground input. Used when adding an alarm to a factory
keyless entry system.
Option 4: Will arm the alarm with a positive (+) 12V input. Used when adding an alarm to a factory
keyless entry system.
