Fantom Vacuum FANTOM FM743H - Manual (Page 10)

1
3
2
4
1 2
1
3
2
4
1 2
Trapdoor
Release Lever
Duster Handle
Turn the duster handle several times in the
direction shown to empty the dust
compartment.
EMPTYING THE DUST COMPARTMENT
Caution: Be sure to turn the ON/OFF switch to the "OFF" position and disconnect the
power cord from the wall outlet before cleaning.
Empty the dust compartment when
contents reach the MAX mark. Press the release button A meanwhile
press the release button B to remove
the dust compartment.
Press the release lever to open the
trapdoor.
Reattaching the Dust Compartment
Close the trapdoor and insert the projection on the
dust compartment into the groove on the main body. Push the dust compartment into
the main body as shown to
reattach.
9
MAX mark
