Data Sheet
⏐ Issue: June 2007⏐ AMILO Pro V3525/V3545 Edition
Page 2 / 3
System AMILO Pro V3545 Edition AMILO Pro V3525 Edition
Processor
Intel Celeron M Processor up to 520 up to 520
Second level cache 1024 1024
Front side bus (FSB) 533 MHz 533 MHz
Intel® Core™ Duo Processor up to T2450 up to T2450
Second level cache 2 MB 2 MB
Front side bus (FSB) 533 MHz 533 MHz
Intel® Core™2 Duo Processor up to T7600 up to T7600
Second level cache 4096 MB 4096 MB
Front side bus (FSB) 667 MHz 667 MHz
Chipset
Northbridge Intel 945PM Intel 945GM
Southbridge ICH 7-M ICH 7-M
Memory
DIMM slots (533, 667 MHz support) 2 2
DDR2-533 SDRAM, 533 MHz up to 2 GB up to 2 GB
BIOS
BIOS Flash EPROM Phoenix First BIOS Phoenix First BIOS
Interfaces
SIM card slot 1 1
Type I/II PC Card slot 1 1
3in1 Card Reader (SD, MMC and memory stick) 1 1
USB 2.0 4 4
S-Video out (TV-out) 1 1
VGA 1 1
Modem RJ-11 1 1
LAN RJ-45 1 1
Audio-in (line-in / microphone) 1 1
Audio-out (line-out / headphone) 1 1
DC-in 1 1
Kensington Lock 1 1
Port Replicator interfaces (optional): - -
Modem on board
56K V.92 modem MDC1.5 x x
LAN on board
built-in 10/100/1000 Mbps Marvell 88E8055 x x
Wireless Technologies (WLAN)
Import and usage according to country-specific regulations.
Dual band antenna
Intel PRO/Wireless 3945 a/b/g x x
Integrated UMTS (HSDPA 1.8 Mb/s), also supported GPRS and EDGE optional optional
Bluetooth
Bluetooth V2.0 optional optional
Audio
Stereo speakers x x
Sound chip RealTek ALC861 RealTek ALC861
Internal microphone x x
Keyboard and pointing device
Keyboard
85 keys, 19mm pitch,
2.5mm key stroke
85 keys, 19mm pitch,
2.5mm key stroke
Touchpad with two mouse buttons with two mouse buttons
Launch keys 2 keys 2 keys
Status LED x x
Graphics
Intel GMA 950 with 256-bit graphics core with dynamic video memory
technology up to 224MB, 32-bit color depth
- x
NVidia GeForce Go 7300 128 MB VRAM (up to 512 MB Turbo Cache) x -
Direct X9 x x
Pixelshader 2.0 x x
DualView (Windows XP and Windows Vista) x x
Display
15.4-inch TFT WXGA / 1280 x 800 pixel x x
Max. resolution for external displays 1600 x 1200 / true color / 85 Hz 1600 x 1200 / true color / 85 Hz
* for made4you customizing projects only
Hard disk drives (internal) *
S.M.A.R.T. - -
60 GB S-ATA 150 (5400 rpm) x x
80 GB S-ATA 150 (5400 rpm) x x
120 GB S-ATA 150 (5400 rpm) x x
160 GB S-ATA 150 (5400 rpm) x x
* 1 Gbyte equals one billion bytes, when referring to hard disk drive
capacity; accessible capacity may vary, also depending on used software
and tool.
** for made4you customizing projects only
Fixed drives
Super Multi DVD writer (incl DVD RAM, 8x double layer support) x x
More information in specific Data Sheet:
http://www.fujitsu-siemens.com/optical_drives/
