FORD 2000 Mustang - Manual (Page 16)

• Base instrument
cluster
• Optional instrument
cluster
Trip odometer
Registers the
kilometers (miles) of
individual journeys.
Press and release the
reset button until a “T”
appears in the display
(this represents the
trip mode). Press and
hold the button for
three seconds to reset.
Battery voltage gauge
This shows the battery
voltage when the
ignition is in the ON
position. If the pointer
moves and stays outside the normal operating range
(as indicated), have the vehicle’s electrical system
checked as soon as possible.
0
0 0 0 0 0 0 0
4
5
6
7
3
2
1
RPMX1000
SELECT/RESET
.
0
0 0 0 0 0 0 0
4
5
6
7
8
3
2
1
RPMX1000
SELECT/RESET
.
0
0 0 0 0 0 0 0
4
5
6
7
8
3
2
1
RPMX1000
SELECT/RESET
.
L H
Instrumentation
16
