INDOOR UNIT

OUTDOOR UNIT

Q’ty

2

2

4

4

1

1

2

2

1

1

Name and Shape

Coupler heat
insulation

Tapping Screw
(flush heads)

Special nut A
(large flange)

Special nut B
(small flange)

Template

Binder
(small)

Blower cover insulation

Hook wire

Remote
control

Remote control cord

Application

For indoor side pipe joint

For installing the remote
controller

For installing indoor unit

For installing indoor unit

For ceiling hole cutting

For fixing the remote
controller cord

For discharged air

For installing intake grille

For connecting the remote
controller

ACCESSORIES

Name and Shape

Q'ty

Application

For outdoor unit drain
piping work (May not be
supplied, depending on
the model.)

1

5

Drain pipe

Drain cap
