FS-8700-112 Gamewell-FCI 7100 Driver Manual Page 8 of 20
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: [email protected]
This parameter tells the driver what to do with
‘Reset’ messages. When not specified or set to
‘Reset_by_any_Node ‘ then the driver will reset
the data array points associated with the given
node irrespective of the reset message’s origin.
When set to ‘Reset_by_this_Node_Only’ then the
driver only resets the data associated with the
given node if the reset originated from the same
node. Reset_by_this_Node_Only
Connection
Specify which port the device is connected to the
FieldServer
P1-P8, R1-R2 1
Example
// Client Side Nodes
Nodes
Node_Name , Protocol , Connection
Panel-01 , FCI_7100 , P1
5.3 Client Side Map Descriptors
5.3.1 FieldServer Related Map Descriptor Parameters
Column Title Function Legal Values
Map_Descriptor_Name Name of this Map Descriptor Up to 32 alphanumeric characters
Data_Array_Name
Name of Data Array where data is to be
stored in the FieldServer
One of the names from Section 0
Data_Array_Offset Starting location in Data Array
0 to (Data_Array_Length -1) as specified
in Section 0
Function Function of Client Map Descriptor. Passive_Client
5.3.2 Driver Related Map Descriptor Parameters
Column Title Function Legal Values
Node_Name Name of Node to fetch data from
One of the Node
Names specified
in Section 5.2
Event_Type
This driver uses this parameter to determine the suitability of
a Map Descriptor when looking for a location to store data
from an incoming message.
A Map Descriptor may be defined to store only ‘Alarm’, ‘Fault’,
‘Trouble’ or ‘Other events. Alternatively, specify “Any”. A
table of events vs. categories is provided in Error! Reference
source not found.
Any, Other, Fault,
Alarm, Trouble
