Fanimation The Benito Ceiling Fan FP8003 - Manual (Page 11)

11
How to Operate Your Ceiling Fan
1. Restore electrical power to the outlet box by turning
the electricity on at the main fuse box (Figure 1).
3. The 5-button hand-held remote transmitter includes
five buttons for high, medium and low fan speeds
as well as fan off and light on/off. Infinite light levels
are available by holding the light on/off button
(Figure 3).
COUPLING
COVER
REVERSE
SWITCH
Figure 4
4. If airflow is desired in the opposite direction, turn
the fan off and wait for the blades to stop turning.
Slide the coupling cover up to expose the reverse
switch. Then slide the reverse switch on top of
motor assembly to the opposite position and turn
fan on again (Figure 4).
Check to see that all connections are tight, including
ground, and that no bare wire is visible at the wire
connectors, except for the ground wire. Do not
operate fan until the blades are in place. Noise and
fan damage could result.
WARNING
Reverse Switch Information
Season Rotation Direction Switch Position
Summer Counter-Clockwise Left
Winter Clockwise Right
MAIN FUSE BOX
Figure 1
Figure 2
REMOTE
3V, CR2032
BATTERY
2 PCS
CONTROL
Figure 3
5-BUTTON
REMOTE
CONTROL
2.
To make fan operational, install two piece of 3-volt
battery in hand-held remote transmitter, (if not using
for long periods of time, remove battery to prevent
damageto transmitter). Store the remote away
from excessive heat or humidly (Figure 2).
