Assembly
• Please wipe each part with a clean, dry cloth before assembly.
• Save all packaging material until assembly is complete to ensure that parts are not discarded.
• Fit the front panel to the back panel.
• Insert two screws through the back panel and into
the front panel. Tighten the screws with a Phillips
screwdriver. Do not over-tighten.
Front
Panel
2
Tabs
Back
Panel
1
Oven Handle
• Fill the cooling drawer with tap water just below the top
of the tubes.
• Place the cooling drawer in your freezer. When the water
in the cooling drawer is frozen, you’re ready to bake.
Before First Use
The cooling drawer must be filled with water
and frozen. The drawer lets the kitchen "bake"
the color change treats.
Cooling
Drawer
• Open the oven door.
• Fit the oven handle to the oven door as shown.
• Insert two screws through the back of the oven door
and into the handle. Tighten with a Philips screwdriver.
Do not over-tighten.
3
• During the assembly you will be making two
electrical connections. Identify the two connectors
coming from the front panel.
Large Connector - Connects to the back panel in the
next step.
Small Connector - Connects to the counter top in
step 10.
Oven Door
Small
Connector
Large
Connector
Top View
