Page 38
MANUAL 599074
36
PARTS LIST
NOTE 1: When ordering replacement part(s), please use part number(s) shown in this parts list. Do not use description of
the part.
NOTE 2: Important safety notice: Components identified by *** have special characteristics important for safety. When
replacing any of these components, please use only manufacturers specified parts.
NOTE:
“A” parts are supplied by MOD (Japan).
“F” parts are supplied by SIMMC (China).
Ref
No.
Part No.
Description
Pcs /
set
Remarks
1
F00068100HN
Caution label
1
4
F10014W00AP
Base
1
5
F10084T00AP
Rubber foot
4
6
F110D4W00BQP
Cabinet body (U)
1
S761BF, S751BF, T791SF
6
F110D4W00HQP
Cabinet body (U)
1
S781WF, S761WF, S751WF
7 ***
F200A4W00AP
Oven (U)
1
S781WF, S761BF/WF, T791SF
7 ***
F200A4W30AP
Oven (U)
1
S751BF/WF
8
F20554W00AP
Cover
1
9
F21314W00AP
Pulley shaft
1
10
F2177-F80
Washer
1
11
F290D9330AP
Roller ring (U)
1
12 ***
F3020-1200
Door hook
1
14
F3136-1200
Hook lever A
1
15
F31374650AP
Hook lever B
1
16
F31384650AP
Hook lever C
1
17
F400A4T10QP
Fan motor
1
AC240V, single phase, 50 Hz
18
F40084T00AP
Fan blade
1
19
F40254W00AP
Air guide A
1
20
F40264W00AP
Air guide B
1
21
F41444W00AP
Orifice
1
22
F84505540AP
Sensor cover B
1
S781WF, S761BF/WF, T791SF
23
F65435540AP
Sensor cover C
1
S781WF, S761BF/WF, T791SF
24
F65434W00AP
Sensor cover C
1
S781WF, S761BF/WF, T791SF
25
A607S4M00AP
Steam sensor
1
S781WF, S761BF/WF, T791SF
26
F612E4J50XN
Incandescent Lamp (U)
1
AC240V, 25W, 50 Hz
27 ***
J61424T00AP
Micro switch
1
(v-15G-3C25-L)
28 ***
J61414T00AP
Micro switch
1
(D3V-16G-3C25)
31 ***
J61784T00AP
Micro switch
1
(Short switch) (D3V-1G-2C25)
32 ***
A606Y4V00GP
H.V. Inverter (U)
1
33
F65854W00AP
Inverter bracket A
1
34 ***
2M261-M32G
Magnetron
1
35 ***
A62304210BP
Fuse
1
10A / 240V, 50 Hz
37
F63264750JP
Turntable motor
1
38 ***
F900C4W00QP
AC cord w/plug
1
39
F66624W00AP
Grounding plate
1
40
XTWFNE4+12T
Screw
4
For magnetron
41
F90804W00AP
Canoe clip
1
For cover
42
XTWAFE4+12D
Screw
5
For cabinet body
43
XTT4+8BFZ
Screw
2
For cabinet body side S761BF, S751BF, T791SF)
43
XTT4+8BCR
Screw
2
For cabinet body side S781WF, S761WF, S751WF
44
J692Y4T00QP
Noise filter
1
45
F0922000EK
Cushion rubber
1
46
F0922000BJ
Cushion rubber
1
47
F0902000AA
Cushion rubber
1
