En-16
OPERATING TIPS
Dry Mode
About 14 to 115 °F
About 64 to 90 °F
Outdoor temperature
Indoor temperature
Cooling Mode
About 14 to 115 °F
About 64 to 90 °F
Heating Mode
About 5 to 75 °F
About 86 °F or less
Temperature and Humidity Range
● If the air conditioner is used under higher temperature conditions than those listed, the built-in protection circuit may
operate to prevent internal circuit damage. Also, during Cooling and Dry modes, if the air conditioner is used under conditions
of lower temperature than those listed above, the heat-exchanger may freeze, leading to water leakage and other damage.
● Do not use this air conditioner for any purposes other than the Cooling, Heating, Dehumidifying, and air-circulation of
rooms in ordinary dwellings.
● If the air conditioner is used for many hours under high-humidity conditions about 80% or more, condensation may form on
the surface of the indoor unit, and drip onto the floor or other objects underneath. (About 80% or more)
TYPE HEAT & COOL MODEL
MODEL INDOOR UNIT MW09Y3H MW12Y3H
OUTDOOR UNIT MR09Y3H MR12Y3H
POWER SUPPLY 208/230 V 60 Hz 208/230 V 60 Hz
COOLING
CAPACITY 8500 BTU/h 11500 BTU/h
INPUT POWER 0.68 kW 0.92 kW
CURRENT 3.3 A 4.3 A
HEATING
CAPACITY 10000 BTU/h 14000 BTU/h
INPUT POWER 0.76 kW 1.12 kW
CURRENT 3.6 A 5.2 A
SPECIFICATION
