4
Double Auto Feed System
• WARNING
• The use of eye protection is recommended.
Do not lean over the trimmer whilst trimming or
edging, objects may be thrown by the cutting
line.
Do not allow cutting head to rest on the ground.
Do not overload your trimmer. Overloading can
be avoided by making sure the motor speed does
not drop unduly.
Disconnect from the mains electricity supply
before attempting any maintenance or adjust-
ment.
• BEFORE USE
Make sure that both lines are fed out.
• Make sure motor is up to full speed before trim-
ming or edging.
How to trim
• The switchbox is provided with a lock-off button
(G1) to prevent accidental starting.
1. Hold as illustrated in Fig H .
2. To start, press the lock-off button down (G1) , whilst press-
ing the lock-off button squeeze the switch lever (G2) .
3. When the trimmer starts release the lock-off button (G1) .
4. Cut with nylon line at an angle using the tip See Fig H.
5. Swing trimmer in and out of the cutting area taking
small cuts. See Fig J.
6. Line is fed out automatically every time the trimmer
head stops rotating and returns to operating speed.
• Extra line can be fed out manually as described on
page 6.
7. To stop your trimmer release the switch lever (G2)
How to edge
1. Hold as illustrated in Fig L .
2. To start, press the lock-off button down (K1) , whilst press-
ing the lock-off button squeeze the switch lever (K2)
3. When the trimmer starts release the lock-off button (K1) .
4. Rest edger on roller for extra stability and line up with the
edge of the lawn, see fig M . Edge in direction indicated
in fig L so that debris is thrown away from you.
5. To stop your trimmer release the switch lever (K2) .
6. To return to trimming mode, turn trimmer over.
•
Ensure the electric cable is not snagged or pulled
around sharp objects.
1
2
G H
1
2
L
K
J
M
How to trim and edge
How the automatic line feed works (F)
1. When initially switching on the trimmer, a small length
of line is fed out.
2. A ‘clattering’ noise will be heard when the two nylon
lines hit the line cutter. DO NOT BE ALARMED this
is quite normal. After approximately 5 seconds the
line will be cut to the correct length and the noise will
reduce as the motor reaches full speed.
• Make sure the motor is up to full speed before
trimming or edging.
3. If the noise of the nylon line being cut cannot be
heard, more line will need to be fed out.
4. To feed more line, it is first necessary to to allow the
motor to stop completely, then re-start, allowing the
motor to reach full speed.
5. Repeat step 4. until you hear the lines hitting against the
cutter. (Do not repeat this procedure more than 6 times)
6. If problems are experienced with the automatic line
feed refer to Fault Finding Chart.
F
line cutter
