PARTS LIST
INDOOR UNIT
Ref. Ord.
No MW24C3F MW24Y3F Q'ty
1 Front Panel Total Assy 67201500 67201540
2 Intake Grille Assy 67201501 67201501
4 Air Filter 67201502 67201502
5 Clamper Grille 67200936 67200936
6 Receiver Window 67201503 67201503
8 Crossflow Fan Assy 67201504 67201504
9 Bearing C Assy 67200922 67200922
10 Casing Assy 67201541 67201541
22 R and L Louver 67201506 67201506
23 SpacerB 67201507 67201507
26 Drain Cap 67201509 67201509
27 EvaporatorAssy 67201542 67201542
28 EvaporatorAssy B 67201511 67201511
29 Connection Pipe Assy 67201543 67201543
30 Distributor Assy 67201544 67201544
31 Water Seal 67201514 67201514
32 Evaporater Holder R 67201515 67201515
33 Evaporater Holder L 67201516 67201516
34 RearBracket 67201517 67201517
35 Filter Guide 67201518 67201518
36 Filter Guard 67201519 67201519
37 Controller PCB Assy 67201545 67201546
38 Control Box 67201521 67201521
39 ControlCover 67201522 67201522
40 MotorCase 67201523 67201523
41 TerminalEarth 67201524 67201524
42 DC Brushless Motor 67201525 67201525
46 Motor, Step 67201526 67201526
47 Motor, Step 67201527 67201527
48 Motor, Step 67201528 67201528
52 GearA 67201206 67201206
53 Terminal 67201529 67201529
55 Display PCB Assy 67201530 67201530
- Remote Controller 67201532 67201547
Part No.
Description
2006.02.23 20
