10
Dash Key Assembly
• Insert and “snap” the key assembly into the opening in
the dash, as shown.
Dash View
Steering
Column
Hole
Bottom View
• Wipe the steering column with a paper towel to remove
any excess lubricant.
• Turn the vehicle on its side.
• Insert the straight end of the steering column up
through the hole in the vehicle body wall and out
through the hole in the dash.
Assembly
5
6
• Insert the end of the steering column through the hole
in the steering rod.
• Fit a cap nut onto the end of the steering column.
• While supporting the steering column, tap the cap nut
with a hammer to secure it on the steering column.
Hint: You may want the help of another person to
support the steering column while you tap the cap nut
with the hammer.
Steering
Rod
Cap Nut
End of
Steering
Column
Bottom View
7
.354"
.354 Cap Nut
