Fisher-Price T0250 - Manual (Page 5)

5
• Lift the frame assembly upright.
• Fit the footrest onto the seat support, as shown.
6
Assembly
• Fit the front base into the frame tubes.
4
• Insert two #8 x ¾" screws with retainers into the holes in
each frame tube and tighten.
Hint: If you cannot insert the screws into the frame tubes, you
have assembled the front base backwards. Remove it, turn it
around and re-assemble it to the frame tubes.
5
Front Base
Footrest
Seat Support
• Insert two #8 x ¾" blunt end screws into the holes on each
side of the footrest and tighten.
7
Footrest
