CHAPTER 1: Overview/Component Replacement
1-1
1.1
Finding Your Way around the FE155
3.1 Introduction
FE155
FE155 Vat
Low Level Float Switch
Upper Level Float Switch
Controller
Lid
8 kW Element
Drain
Inlet
Overflow
Bezel
NOTE: The water inlet is
controlled by the main
power switch. It must be
off during draining and
cleaning to ensure the
vat doesn’t refill.
Probe
16.5 Gal vat
