PROFESSIONAL
■ BWF or SDII™ audio file formats in 16-bit or
24-bit resolution (on the same disc)
■ Fostex Verify/Write feature constantly
examines data being recorded to DVD-RAM
(not 96kHz/4tr or 192kHz/2tr)
■ UDF (Universal Disc Format) on DVD-RAM
allows discs to be mounted & read instantly on
both PC and Mac platforms
■ Mono, stereo or 4-track recording modes. Full
on-board copy, paste, insert, cut and erase
features with high precision scrubbing
■ Full timecode facilities
■ Avid™ compatibility. BWF files recorded on the
DV40 can be imported directly into Avid Film
Composer (depending on software version)
along with information about Scene, Take, Reel
Number, Event, etc. being transported and read
from the files Metadata. The Metadata area is
user-editable for future expansion
■ Circle Take to mark files/takes for easy
identification leading to quick imports and EDL
references
■ Up to 100 cue points per file/take
■ Alpha numeric keypad for quick file/take &
track naming, EDL manipulation, location, etc.
■ Large high-resolution (200 pulses per rotate)
jog/shuttle dial and clever digital tracking
technology result in super-accurate audio
scrubbing
■ EDL management built-in to create & edit
multiple ALE (Avid™ Log Exchange)
compatible edit decision lists per DVD-RAM.
■ Large multi-function fluorescent display,
oversized illuminated transport keys
■ Future software developments and updates
implemented via CD or DVD and built-in
Ethernet via PC available for download from the
dedicated web site: www.fostexdvd.net
■ Excellent compatibility - can read other
manufacturers DVD-RAM discs containing
FAT16 formatted BWF files
■ External Word & Video sync inputs and Word
Output plus parallel remote connector
■ Dedicated ADR (Automatic Dialogue
Replacement) software features built-in
■ Comprehensive I/O including 24 bit/192kHz on
balanced XLR and 1/4" phone jacks; AES/EBU
digital
■ 10/100 BASE-T Ethernet networking for easy
integration into production networks
■ DAT ‘cloning’. Monitors timecode input during
recording of DAT to DVD-RAM and creates a
new file automatically whenever timecode goes
‘discontinuous’
■ Automated file/take naming routine speeds
set-up time between takes complying to US
and Euro standards. Individual track naming
rolls through to next file/take until changed by
user, if required
■ Comprehensive software selectable UBIT
output format combinations including Scene,
Take, Event no., etc.
■ Optional
Model 5050
With the new
optional Model
5050 card fitted,
the DV40 can
read the 6 track
files created by
the PD-6 simply
by removing the
8cm DVD-RAM
from its case and
placing it in the
DV40's tray.
In addition, analog outputs 5 & 6 are provided
on balanced XLR connectors as well as
AES/EBU on XLR. A software update provided
with Model 5050 allows the meters to be
switched between all six channels.
Main Features
Working hand-in-hand with post production facilities, sound mixers, radio
stations and ADR suites, Fostex’s continual development of the DV40
mastering machine means that it‘s ready to handle every application and
exception in today’s, and tomorrow’s, constantly changing and challenging audio
environments.
Able to record four simultaneous non-destructive audio tracks to DVD-RAM at up to 24 bit /
192kHz resolution and with its elegant timecode implementation, the DV40 has quickly become
the machine of choice for many film and tv productions in the US, Europe and beyond helping to
streamline the production process and hence reduce costs.
Post production houses too have warmed to the DV40. The handy Universal Disc Format (UDF),
which allows DV40 media to be mounted and read by Macintosh and PC workstations, easy
media network integration and ultra-fast, rock solid synchronisation, is revolutionising many
productions from LA to London.
Of course what really sets the DV40 apart is its
elegant handling of timecode as it addresses the
challenges presented by today’s ‘random access’
requirements: able to synchronise with both external
word and video signals, the built-in timecode
generator is fully featured and even includes the new
23.976 frame HD camera mode.
Continuous development has seen the recent
introduction of the Model 5050 card which allows the
DV40 to read the 6 track files created by the PD-6,
new enhanced ‘take’ (file) naming complying with US
and European clapper board standards and EDL
management tools allowing ALE (Avid Log Exchange)
compatibility.
The perfect production partner to a PD-6 or the
ultimate timecode master recorder. The DV40 is all
this. And more.
timecode generator clear fluorescent display alpha numeric key pad headphone monitoring freque
DVD Master Recorder
DV40
