FS-8700-123 MetOne Particle Counter Driver Manual Page 7 of 22
FieldServer Technologies 1991 Tarob Court Milpitas California 95035 USA Web: www.fieldserver.com
Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: [email protected]
5 CONFIGURING THE FIELDSERVER AS A METONE PC SERIAL CLIENT
For a detailed discussion on FieldServer configuration please refer to the FieldServer Configuration Manual. The
information that follows describes how to expand upon the factory defaults provided in the configuration files
included with the FieldServer (See “.csv” sample files provided with the FieldServer).
This section documents and describes the parameters necessary for configuring the FieldServer to communicate
with a MetOne Particle Counter Serial Server.
The configuration file tells the FieldServer about its interfaces and the routing of data required. In order to enable
the FieldServer for MetOne Particle Counter Serial communications the driver independent FieldServer buffers
need to be declared in the “Data Arrays” section the destination device addresses need to be declared in the
“Client Side Nodes” section and the data required from the Servers needs to be mapped in the “Client Side Map
Descriptors” section. Details on how to do this can be found below.
Note that in the tables * indicates an optional parameter with the bold legal value being the default.
5.1 Client Side Connection Descriptions
Section Title
Connections
Column Title Function
Legal Values
Port Specify which port the device is connected to the FieldServer P1-P8 R1-R2 1
Protocol Specify protocol used MetOne
Baud* Specify baud rate 9600 (Vendor limitation).
Parity* Specify parity None (Vendor limitation)
Data_Bits* Specify data bits 8 (Vendor limitation)
Stop_Bits* Specify stop bits 1 (Vendor limitation)
Poll_Delay* Time between internal polls 0-32000 seconds 0.05s
Example
// Client Side Connections
Connections
Port , Protocol , Baud , Parity , Poll_Delay
P8
, MetOne , 9600 , None , 0.100s
1 Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction manual for details of the ports available
on specific hardware.
