SPECIFICATIONS
DESIGNATION TYPE PR 200
OUTPUT POWER Stereo Continuous sine wave output power,
both channels driven +/- 1dB, 20 Hz to 20kHz, THD < 0.03%
150 W into 8
Ω
, each channel
300 W into 4
Ω
, each channel
MONO BRIDGE 300 W into 16
Ω
600 W into 8
Ω
SINGLE CHANNEL DRIVEN @ 1 kHz, 1% THD 8
Ω
179W
4
Ω
312W
POWER BANDWIDTH 10 Hz to 68 kHz
(3 dB down from rated power at less than 0.1% THD)
FREQUENCY RESPONSE +0 -3dB; 5 Hz to 68 kHz (at rated power, 8
Ω
)
RISE TIME Less than 5.2 µSec
SLEW RATE Greater than 13.5 V/µSec
TOTAL HARMONIC
DISTORTION (THD)
20 to 20 kHz at rated power, 4
Ω
. Less than 0.03%
HUM AND NOISE Below rated output, 4
Ω
20 Hz to 20 kHz broad band 95 dB
IEC A Weight 102 dB
DAMPING FACTOR Reference, 8
Ω
5 Hz to 20 kHz Greater than 30
1 kHz Greater than 175
INPUT IMPEDANCE Differential 33 k
Ω
CHANNEL SEPARATION Below rated power, single channel operating
1 kHz, Greater than 65 dB
SENSITIVITY Referenced 1 kHz, +/- 0.25 dB
Stereo Mode +1.8 dBV (1.23V)
Bridged Mode +1.8 dBV
STATUS INDICATORS Each channel-Peak LED (red)
Power LED (green)
COOLING Two speed fan
GAIN CONTROLS Continuously variable attenuator, one per channel
MODE SWITCHING Stereo-Mono Bridge, Stereo-Dual Mono, two push button
switches
POWER REQUIREMENTS 1000W
DIMENSIONS
Weight 25 lbs. (11.3 kg)
Height 3.5 in. (8.9 cm)
Width 19 in. (48.3 cm)
Depth 15 in. (38 cm)
7
THIS EQUIPMENT CONFORMS TO
THE FOLLOWING DIRECTIVES :
EMC 89/336/EEC AND LV 73/23/EEC
A PRODUCT OF:
FENDER MUSICAL INSTRUMENTS CORP.
CORONA, CA 91720 USA
