FORD 2005 Ford GT - Manual

*F5G7J19G217AB*
5G7J-19G217-AB
This Quick Reference Guide is not intended to replace your vehicle Owner’s Guide which contains more detailed information
concerning the features of your vehicle, as well as impor tant safety warnings designed to help reduce the risk of injur y to
you and your occupants. Please read your entire Owner’s Guide carefully as you begin learning about your new vehicle and
refer to the appropriate sections when questions arise.
All information contained in this Quick Reference Guide was accurate at the time of duplication. We reser ve the right to
change features, operation and/or functionality of any vehicle specification at any time. Your Ford dealer is the best source
for the most current information.
For detailed operating and safety information, please consult your Owner’s Guide.
FORD GT
05
2005 QUICK REFERENCE GUIDE
FUEL FILL
When filling your vehicle with fuel, turn the engine off. Unlock the fuel door by
inser ting and turning the key in the lock cylinder on the passenger side fender.
After unlocking, pull the aluminum handle to unlatch the fuel door. Inser t the
fuel nozzle fully into the filler pipe and use the nozzle to slide the plastic cover
to the side.
1
4
5
6
7
8
additional features
05
FORD GT
REMOTE ENTRY SYSTEM
Unlock: Press and release the unlock button once to unlock the driver's
door, and twice to unlock both doors. The interior lamps will illuminate and
the park lamps will flash twice after each press of the button.
Lock: Pressing the lock button twice will cause the park lamps to flash
twice and the horn to chirp once. If either of the doors, the luggage
compar tment or engine cover is not properly closed, the car's horn will
make two quick chirps.
Luggage Compar tment: Press the button once to open the compar tment.
This feature will only operate when the ignition is in the OFF position.
Panic Alarm: Press the button to activate the alarm. Press the control
again, or turn the ignition ON to deactivate. The alarm will only operate
when the ignition is in the OFF position.
EXTERIOR LUGGAGE COMPARTMENT RELEASE
Unlock the trunk or front compar tment by inser ting and turning the key in the lock
cylinder on the driver’s side. After unlocking, pull the aluminum handle to unlatch
the front compar tment. The compar tment may also be opened by pressing the
button on the keyfob. Ford Motor Company, Customer Relationship Center, P.O. Box 6248, Dearborn, MI 48121
1-800-392-3673 (FORD) (TDD for the hearing impaired: 1-800-232-5952)
2
3
8
1
2
3
4
5
9
AM/FM MCINTOSH CD SYSTEM
CLIMATE CONTROLS
BASS/TREBLE: Press the control to enter bass mode. The control will pop up to allow you
to turn it left or right, which decreases or increases the amount of bass output. Pull the
control toward you again to enter treble mode. Turn left or right to decrease or increase the
amount of treble.
ON-OFF/VOLUME/BALANCE: Turn the control to the right to activate the system. Turn the
control fur ther to the right to increase volume or to the left to decrease volume. To shut the
system of f, turn the control to the left until the display turns of f. Pull the inner control out
and turn it to the left or right to shift the balance of sound between the left and right
speakers. After making the desired selections, push the control back to its original position
to save the current adjustments.
AUTOSTORE/REPEAT: Press to automatically store the strongest radio stations on the selected
frequency or to play the current CD track repeatedly.
MEMORY PRESETS: In CD mode, use the buttons to select a stored CD. A total of 24
stations can be stored in your system – six in each band. In radio mode, use the numbered
preset buttons to select stored stations. Press the AM/FM button to select a frequency band,
turn the tune control to select a station, then press and hold the desired memor y preset
number. The sound will mute. When the station is stored, the sound will return and the
indicator light above the control will illuminate.
1
2
3
4
5
6
7
8
DISPLAYING THE CLOCK: While pressing and holding the AM/FM band control, press and
release #4 preset control. Each time the operation is repeated, the display switches between
the mode and clock. Setting the Clock: Set the display to clock mode (press and hold AM/FM
while you press and release the #4 preset control). While pressing and holding the AM/FM
band control, press and hold #4 preset control for three seconds longer. Clock display will
flash. Turn and release the TUNE control to the right to advance the minutes incrementally. Turn
and hold to advance the minutes continually. Turn and release the TUNE control to the left to
advance the hours incrementally. Turn and hold to advance the hours continually. When the
correct time is set, press AM/FM band control to confirm the current time.
AM/FM: Press the button to switch between FM1, FM2, FM3, and AM frequency bands.
LISTEN/TUNE: Turn the inner ring right/left to incrementally go up/down the radio frequency, or
to select a track. Turn and hold to seek up or down the radio frequency. To change mode
(Radio, CD), turn and release the outer ring. The mode will appear on the display.
EJECT: Press to eject a CD when the power is on or off.
A blinking red light on your radio does not indicate a problem. It is a theft-deterrent and can be
activated and deactivated by pressing and holding the Eject button for two seconds with the
radio powered off.
AIRFLOW SELECTIONS: Controls the direction of the air flow in the vehicle.
Distributes air through the instrument panel vents.
Distributes air through the instrument panel vents and the floor vents.
Distributes air through the floor vents.
Distributes air through the windshield defroster vents and floor vents. The system
automatically provides outside air to reduce window fogging.
Distributes outside air through the windshield defroster vents. Can be used to clear ice or fog
from the windshield. The system automatically provides outside air to reduce window fogging.
FAN SPEED ADJUSTMENT: Controls the volume of air circulated in the vehicle.
A/C: Press the button to engage or disengage this function. When the A/C is on, it
distributes outside or recirculated air through the selected vents to cool the vehicle.
Note: A/C cannot be activated without fan speed adjustment being activated.
TEMPERATURE SELECTION: Controls the temperature of the air flow in the vehicle.
RECIRCULATED AIR: Press the button to engage or disengage to select fresh or
recirculated air operation. When used with A/C, recirculated air reduces the amount of
time required to cool down the interior and may help to reduce undesired outside odors
from entering the vehicle.
essential information
ROADSIDE EMERGENCIES: In addition to your New Vehicle Limited Warranty, Ford provides new vehicle
owners with a complimentar y roadside assistance program. This ser vice is available 24/7 for three years
or 36,000 miles (60,000 km).
FUEL TANK CAPACITY: Your fuel tank holds
17.5 gallons (66.2L) of fuel.
TIRE PRESSURE: Your tire pressure is set at the dealership
according to the specifications on the Cer tification Label on the
trailing edge of the driver’s door. Additional tire pressure
information regarding high speed use can be found on
the tire label located on the lower B pillar.
VEHICLE HEIGHT: The height of your vehicle is
44.3 inches (1125 mm).
FUEL PUMP SHUT-OFF SWITCH: This device stops
the electric fuel pump from sending fuel to the engine
when your vehicle has had a substantial or severe road
impact, such as a large bump or dip in the road.
After a collision, if the engine will crank but not star t, your
shut-of f switch may need to be reset.
The switch is located in the front passenger’s footwell, behind an access panel. To access the switch, roll
back the carpet and remove the four screws on the access panel. See the Roadside Emergencies chapter
of your Owner's Guide for more information.
1
2
3
4
5
ELECTRIC DOOR RELEASE
To open the door, press the unlock icon on the keyfob. Then push the
release button on the door.
