*FREUD* FRESADORA * FIXED BASE ROUTER * DEFONCEUSE *
643
1/2
LISTA DE RECAMBIOS / SPARE PART LIST / LISTE PIECES DETACHEES
VERSION: 1-0
POS CODIGO VERS. DENOMINACION DESCRIPTION DENOMINATION
1A 136068421 Cuerpo soporte Support body Corps supporte
1B 136069761 Gr. Cuerpo+base (incl.piezas "*") Body ass.(inc. parts marked "*") Gr. corps (inclut pieces "*")
2A 136065321 V-0 Cuerpo cubierta Housing body Corps couverte
2B 136065322 V-1 Cuerpo cubierta Housing body Corps couverte
3 136065531 Placa apoyo Base plate Plaque base
4 136061031 Cubierta motor Top motor housing Carcasse moteur
5 136061062 Casquete cubierta motor Motor housing cap Couvercle carcasse
6 136064023 Boton bloqueo Stop rod button Bouton blocage
7 136062611 V-0 Guia de aire Air guide Guide d'air
8A 136069031 V-0 Inducido 120V 120V Armature Induit 120V
8B 136069061 V-1 Inducido 120V 120V Armature Induit 120V
9 134344022 Boton interruptor Power switch lever Bouton interrupteur
11 136069021 Estator 120V 120V Field Stator 120V
12 136069861 Gr.tornillo+soporte ajuste profun. Depth+support adjustment screw Vis+support adapte profondeur
14 136068371 Boton fijacion eje Spindle lock button Bouton fixation axe
15 136063851 Protector polvo Dust cover Protecteur poussière
18 136064201 Placa interruptor Switch plate Plaque interrupteur
19 136064451 Soporte placa interruptor Switch support plate Support plaque interrupteur
21 757001250 Muelle Spring Ressort
22 136065671 Palomilla ajuste profundidad Height adjustment knob Vis papillon adapte profondeur
23 136065052 Escala ajuste profundidad Height adjustment knob scale Échelle adapte profondeur
25 763488119 Modulo control velocidad Speed control module Module contrôle vitesse
26 136065631 Cubierta puño Handle cover Couverture poignee
27 136065641 Cuerpo Puño Handle body Corps poignee
31 712000026 Rodamiento 6000LLU Bearing 6000 LLU Roulement 6000LLU
32 870800914 Arandela bloqueo Lock washer Rondelle blocage
33 712000535 Rodamiento 6005LLU Bearing 6005 LLU Roulement 6005LLU
35 844315252 Tornillo M4x12 Screw torx M4x12 (3) Vis M4x12
36 136061521 Tapa rodamiento Bearing shaft nut Couverture roulement
37A 136037411 Tuerca pinza Collet nut Ecrou pince
39 870800513 Arandela 5x13x2 Washer 5x13x2 (2) Rondelle 5x13x2
40 136064711 Rulina selector velocidad Speed dial selector vitesse
41 849077150 Tornillo M5x10 Screw torx M5x10 (2) Vis M5x10
42A 847615248 Tornillo placa apoyo Base plate screw (4) Vis plaque appui
42B 847615248 Tornillo Arandela lateral Flange washer screw (1) Vis rondelle latérale
42C 847615248 Tornillo Arandela ajuste Tightening washer screw (2) Vis rondelle adapte
43 842010344 Tornillo puño M6x50 Handle screw M6x50 (2) Vis poignee M6x50
44 844830134 Tornillo TP 5x55 Screw TP 5x55 torx (2) Vis TP 5x55
45 134132251 Muelle escobilla Brush spring (2) Ressort balai
46 135289112 Porta escobilla Brush holder Porte balai
47A 134109075 Escobilla Motor brush Balai
47B 134109076 Escobilla auto Motor brush auto Balai auto
48 844820028 Tornillo 3,5x16 Screw 3,5x16 torx (2) Vis 3,5x16
49A 842009301 Tornillo brida desbloqueo Un locking clamp screw (1) Vis bride déblocage
49B 842009301 Tornillo cubierta motor Top motor housing screw (4) Vis couverte moteur
50 101204231 Brida cable Cable clamp Bride câble
51 844820050 Tornillo 4x20 Screw 4x20 torx (2) Vis 4x20
52 763256021 Interruptor Power switch Interrupteur
53 134314181 Manguito cable Power cord boot Manchon
54 767663500 Cable toma corriente Power cord Câble prise courante
55 844820048 Tornillo M4x16 Screw 4x16 torx (4) Vis M4x16
56 842010256 Tornillo M4x16 Screw M4x16 Vis M4x16
57 742102515 Anillo goma Rubber ring Anneau gomme
58 136027431 Pinza 1/2" 1/2" Collet Pinze 1/2"
66 136068841 Brida desbloqueo Un locking clamp Bride déblocage
67 136063911 Tuerca Nut Ecrou
68 136065132 Palanca brida Clamp lever Levier bride
69 136065811 Pivote palanca Lever pivot Pivot levier
70 842009340 Tornillo M6x40 Screw M6x40 DIN 912 Vis M6x40
73 101611421 Junta torica 5x1,5 5x1,5 o-ring Joint torique 5x1,5
74 136082881 Tope goma Rubber stop Stop gomme
76 136064029 Lengüeta retención Retaining tongue Languette retenue
77 136066912 Arandela rectangular Plate washer Rondelle rectangulaire
78 136065502 Ajuste bloqueo puño Adjusting lock handle Ajustement blocage poigne
79 136066900 Arandela ajuste Tightening washer Rondelle ajust
80 136066940 Arandela lateral Flange washer Rondelle latérale
81 136064961 Rueda ajuste up/down Up/down knob Roue ajustement up/down
82 136064951 Rueda micro-ajuste Micro adjustment wheel Roue micro- ajustement
83 870801021 Arandela Washer Rondelle
84 136062614 V-1 Guia de aire Air guide Guide d'air
ACCESORIOS ACCESSORIES ACCESOIRES
37B 136037411 Tuerca pinza Collet nut Ecrou pince
109 136025211 Llave 22mm Wrench 22mm Clé 22mm
110 919340000 Adaptador aspirador Vacuum adapter Adaptateur aspirateur
111 844315288 Tornillos guía plantilla Template guide screws Vis guide calibre
112 136027435 Pinza 1/4" Collet 1/4" Pinze 1/4"
114 847305327 Tornillo montaje tabla Table mount screw Vis assemblage tableau
