OPTIONAL EXTERNAL
BATTERY CONNECTOR
OUTPUT
RECEPTACLES
(6 places without
external battery
option, 4 places as
shown)
COVER PLATE
FOR
OPTIONAL
DIP SWITCHES
RS-232
CONNECTOR
COOLING FAN
DO NOT BLOCK
INPUT CIRCUIT BREAKER
BATTERY FUSE
POWER INLET
SG800-1T & SG1K-1T
Typical Rear Panel Overview
SG800-2T & SG1K-2T
Typical Rear Panel Overview
OPTIONAL EXTERNAL
BATTERY CONNECTOR
OUTPUT
RECEPTACLES
4 each IEC 320
COVER PLATE
FOR OPTIONAL
SNMP AGENT
DIP SWITCHES
RS-232
CONNECTOR
COOLING FAN
DO NOT BLOCK
INPUT FUSE
BATTERY FUSE
POWER INLET
12
CHAPTER 4 CHAPTER 4
REAR PANEL DETAILS
Please verify the UPS output
ratings match your
requirement
