Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box
Description
15
40A**
Heated mirror
16
40A**
Blower motor
17
30A**
Trailer tow electronic brakes
18
—
Not used
19
—
Not used
20
—
Not used
21
20A*
Rear of console power point
22
20A*
Subwoofer
23
20A*
4x4 module
24
10A*
Powertrain Control Module
(PCM) KAP, CAN vent
25
20A*
Front of console power
point/Cigar lighter
26
20A*
4x4 module
27
20A*
6–speed transmission control
module (TCM)
28
20A*
Heated seats, Power mirror
29
15A*
Right high/low beam headlamp
30
20A*
Cargo bed power point
31
15A*
Fog lamps
32
5A*
Power mirrors
33
30A*
ABS valves
34
15A*
Left high/low beam headlamp
35
10A*
AC clutch
36
—
Not used
37
30A*
Front wiper
38
15A*
5–speed transmission
39
15A*
PCM power
40
15A*
Fan clutch, PCV valve (4.0L
engine only), AC clutch relay
41
15A*
SDARs/DVD
