Technical Specifications
DVD-RAM Technical Data
*The value is in the case of Mode 1 recording, capacity varies by the format in use.
• Figures are marked with * are comparisons with the Fujifilm reference tape.
• Please note that the DV digital video system is NOT compatible with analog video systems. • Two sizes of cassettes are
available for the DV digital video system – the Mini DVCassette and the DVCassette. The latter is suitable for extended recording
and playback. • In accordance with copyright laws, Mini DVCassette recording are for private viewing only. • Mini DV is a
commercially registered logo. • Specifications and appearance are subject to change without notice for product improvement
purposes. Color and packing may differ from that shown in the catalog.
DVCassette Mini DV/ HDV DV 63S Technical Data
Basic Specifications
Physical Characteristics
Operating Environments
Capacity (Unformatted) 9.4 GB 4.7 GB 4.7 GB
(double-sided) (single-sided) (single-sided)
Recording Method Edge-mark recording system
Bytes / Sector 2,048 Bytes
Sectors / Track 25 - 59 (ZCLV)
Track Pitch 0.615 µm
Track Format Wobbled land and groove
Recording Speed Up to 3x
Outer Diameter 120.0 mm
Thickness 1.2 (0.6 x 2) mm
Cartridge Type 4 Non-cartridge
(Removable) type
Temperature 5 ~ 60 ºC
Humidity 3 ~ 85 % RH (Wet-bulb Temperature 29 ºC or lower. No dew condensation.)
CD-R/CD-R PRO for Audio/ CD-RW Technical Data
CD-R for Digital Photos Technical Data
CD-R CD-R PRO for Audio CD-RW 4x-12x
Format Orange Book Part II Orange Book Part III
Capacity 700 MB
Recording Time 79 min. 57 sec.
Linear Velocity 1.2 m/s 4.8 - 14.4 m/s
Track Pitch 1.5 µm 1.5 µm ±0.1
Substrate Material Polycarbonate
Recording Layer Organic Dye Phase Change Material
Outer Diameter 120.0 ±0.3 mm
Inner Diameter 15 mm + 0.1 / - 0.0
Thickness 1.2 + 0.3 / - 0.1
Recording Areas 44.7 to 118 mm (max.) 50 to 116 mm
Temperature - 5 ~ 55 °C
Humidity 5 ~ 95 %RH
Wet Bulb < 29
Basic Specifications
Physical Characteristics
Operating Environments
(1) This is the disc that will enable you in the future to write and rewrite using High Speed CD-RW drives that are available
from major drive manufacturer. Use after verifying that your drive is compatible with High Speed CD-RW.
High Speed CD-RW drives have the High Speed CD-RW logo on the left (1). Writing and rewriting can not be done with
existing 1 x 2 x 4 CD-R/RW drives, which have the logo on the left (2), but not the logo (1).
(2) (1)
Recordable in High speed CD-RW drives with logo (1)
DVM60 DVM80 HDV DV 63S
Coercivity (Hc) 120 kA/m 120 kA/m
Retentivity (Br) 450 mT 500 mT
Squareness (Br / Bm) 0.8 0.8
Tape Width 6.35 mm 6.35 mm
Tape Thickness 7 µm 5.3 µm 7 µm
Optimum Recording Current 0 dB* 0 dB*
Data Signal Output Level (21 MHz) More than - 1 dB* More than 0 dB*
Frequency Response (21 MHz / 10.5 MHz) ±2 dB* within ±2 dB*
Overwrite Level (21 MHz / 10.5 MHz) Less than + 2 dB* Less than 2 dB*
C/N (21 MHz) More than - 2 dB* More than - 1dB*
C/N (10.5 MHz) More than - 2 dB* More than - 1dB*
Tracking Signal Output Level (0.47 MHz) 0 dB* 0 dB*
Tracking Signal Overwrite Level (0.47 MHz / 21 MHz) Less than + 1dB* Less than - 1dB*
Impulse Response ±5 % within ±5 %
Magnetic Properties
Physical Properties
Recording Characteristics
Basic Specifications
Format Orange Book Part II
Capacity 700 MB
Linear Velocity 1.2 m/s
Track Pitch 1.5 µm
Substrate Material Polycarbonate + Black Protection Shield
Recording Layer Organic Dye
Outer Diameter 120.0 ±0.3 mm
Inner Diameter 15 mm + 0.1 / - 0.0
Thickness 1.2 + 0.3 / - 0.1
Recording Areas 44.7 to 118 mm (max.)
Optimum Write Power 6 ~ 7 mw (Laser W/L = 790 mm, Lens = 0.5)
Number of Readings More than 10 times 6
