When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
OUTDOOR UNIT
1
Top Panel Assy
9309230057
2
Top Panel Seal
9309228016
3
Cabinet Sub Assy
9314809040
4
Blow Down Grille
9308884015
5
Cabinet Right Assy
9309236011
6
Fan Ring
9308885012
7
Grip
9308880017
8
Switch Cover Assy
9309237049
10
4-Way Valve
9970056017
11
Expansion Valve Assy
9311641018
12
Strainer
9311440017
13
Condenser Assy
9311382027
14
Thermistor Spring-A
313728262708
15
Thermistor Spring-A
9300089012
16
Propeller Fan
9309909014
18
Motor Bracket
9308872012
19
Separator
9312971015
20
Base Assy
9308869081
21
3-Way Valve Assy
9315159014
22
2-Way Valve Assy
9313064013
24
Cord Clamp
9307271014
25
Terminal
9703874024
26
Inverter PCB Assy
9707039085
29
Fuse
0600382018
32
Expansion Valve Coil
9900057039
34
Fan Motor
9602133017
35
Compressor Assy
9313764012
36
Emblem Rear
9312661015
37
Heat Exchanger Thermistor
9900148027
Thermistor
39
Solenoid Coil
9970033025
---
---
IPM
9705720015
---
Outdoor Temp. Thermistor
9900210045
9900041014
Thermistor Assy
---
9900148027
Ref.
No.
Description
Part No.
MR18Y3F
Ord.
Q'ty
2006.02.20
FOLS checked 2006/01/17
