M-6007-B50/B51/XE3/XB3
Engine
INSTRUCTION SHEET
NO PART OF THIS DOCUMENT MAY BE REPRODUCED WITHOUT PRIOR AGREEMENT AND WRITTEN PERMISSION OF
FORD RACING PERFORMANCE PARTS
IS-1850-0088
Page 6 of 6
Tech “Hot Line” (586) 468-1356
Factory Ford shop manuals are available from Helm Publications, 1-800-782-4356
5.0L SPECIFICATIONS:
Bore: 4.0
Stroke: 3.0
Displacement: 302
CID
Nominal Compression Ratio: 9.0:1
Block Height: 8.206
Piston to Deck: .0075 below to .0135 above
Camshaft: (Hydraulic Roller) M-6250-B303 M-6250-E303
Maximum Valve Lift .480 Maximum Valve Lift .498
Duration at .050 lift 224 Duration at .050 lift 220
Intake Centerline 107 Intake Centerline 110
Lifters: Current
production
Valves: M-6007-B50/B51/XB3/XE3
M-6507-J302/M-6505-G302
Valve Springs: M-6513-A50
Rocker Arms: Current Production 5.0L GT
Combustion Chamber Volume:
M-6007-B50/B51/XB3/XE3 64cc nominal
TORQUE SPECS:
Main Bearing Bolts
60-70 ft./lbs.
Rod Connecting Nuts 19-24 ft./lbs.
Cam Sprocket Bolt 40-45 ft./lbs.
Damper Bolt 70-90 ft./lbs.
Flywheel Bolts 75-85 ft./lbs.
Rocker Arm Fulcrum Bolts 18-25 ft./lbs.
Head Bolts (Conventional) 1 st : 55-65 ft./lbs.
2 nd : 65-72 ft./lbs.
*Head Bolts (Torque to Yield)
1 st : 35 ft./lbs.
2 nd : 55 ft./lbs.
3 rd : ¼ turn
Intake Bolts 18 ft./lbs. Maximum with aluminum heads
*Utilized in FRPP M-6051-A50 high performance gasket kits
