24G SERIES FLATBOTTOM GAS FRYERS
CHAPTER 2: PARTS LIST
2-15
2.4.6 Frypot, Drain, and Oil Return Components – SCFC Models (cont.)
ITEM PART # COMPONENT
1 826-1821 Frypot Kit, 1824G (Front Drain, Front Return) (use 826-1821 for 2424G)
2 823-3934 Divider, Frypot
3 823-3174 Plug, Frypot Drain
4 823-3190 Baffle, Secondary Air
5 210-1409 Spreader, Side Flame
6 823-4062 Firebox Assembly
* 826-2036 Insulation, Pot FB
7 220-3512 Guard, Firebox, Bottom
8 812-1822 Tube, Drain, RH
9 812-1823 Tube, Drain, LH
10 812-2017 Tube, Drain, Center Dump
11 816-0729 Sleeve, Drain Tube Connector
12 809-0969 Clamp, 3" T-bolt
13 106-5461 Oil Return Plumbing (attaches to Section 2.3.1.2, Item 19 at the back of the unit)
810-2125 Drain Valve, ⅜-inch Bal Valve
810-3011 Tubing, Front
810-3014 Tubing, Rear
813-0165 Elbow, ½" x ½" Street , 90°
813-0462 Coupling, ⅜-inch
813-0613 Fitting, ½-inch x ½-inch 37° Flare
813-0614 Fitting, ½-inch x ⅜-inch 37° Flare
813-0631 Elbow, ⅜-inch x 90°
813-0649 Nipple, ⅜-inch NPT x 2.50 inch
813-0894 Elbow, ½-inch x ⅜-inch 37° Flare
14 106-4006 Drain Valve with Microswitch, ½"
* 816-0211 Sleeve, Red Valve Handle
* 807-2104 Microswitch, Drain Valve Roller Lever (use 902-2348 for M/S Guard)
* 813-1790 Nipple, 1¼-inch x 5.85 inch NPT Toe
* 813-0165 Elbow, ½-inch x 90° NPT Street
* 813-0632 Elbow, ⅜-inch x 90° NPT Street
* 810-2125 Valve,
⅜-inch Oil Return Ball (use 200-1143 for Nut Retainer)
* 823-5815 Handle, UFF Oil Return
* 816-0548 Cap, Yellow Vinyl Oil Return Handle
* 810-3014 Tube, Front Oil Return
* 200-4725 Guard, Probe and High-Limit
* 210-1433 Clamp, Probe and High-Limit Bulb
* 200-4505 Plate, Drain Nipple Closure
* 812-1515 Nipple,
⅜-inch x 2.345-inch NPT Toe
* Not illustrated.
