EH1721 SERIES ELECTRIC FRYERS
CHAPTER 4: BUILT-IN FILTRATION
4-1
4.1 Filtration Preparation
On initial installation and before each use, remove all loose parts from the filter, wash the filter pan
and all accessories in hot, soapy water and dry thoroughly.
4.1.1 Assembling the Filter
The Single Under Fryer/Under Fryer Filter (SUFF/UFF) uses filter paper held in place by a hold-
down ring to filter impurities and debris from the cooking medium. The filter pan is assembled with
the following components (see illustration below):
1. Filter pan.
2. Filter support grid.
3. Filter paper.
4. Hold-down ring.
5. Crumb screen.
6. Front pan cover.
7. Rear pan cover.
1
2
3
4
5
6
7
