2
Figure 2. Closed Case (Top)
To open the case, unzip the wraparound zipper (Figure 2)
and lift the cover. Open the case so that it lies flat.
Notebook Configuration
To use your system in notebook configuration (Figure 3):
1.
Unzip the case and lay the system into the case base.
2.
Open your computer so that the display is in notebook
configuration (perpendicular to the keyboard).
Prior to installing the notebook into the bump
case, remove the pen. Once the system is
installed, you will not be able to remove the
pen. Store the pen in the pen holder. (Figure 2)
Wrap-around Zipper
Protective Cover
Pen Holder
