Electrical 7
For parts or assistance, call Flotec Customer Service at 1-800-365-6832
To Convert 230 Volts to 115 Volts, Plug-in type
(see Figures 5 and 6).
1. Unplug the motor.
2. Loosen the two screws on the end of the motor.
Gently pull the canopy from the motor.
NOTICE: Do not pull or jerk wires.
3. Connect the green (or bare copper) ground wire to
the green ground screw first (see Figures 5 and 6).
Use a solid copper wire at least as large as the power
supply wires.
4. Pull the plug straight out from the terminal board,
from 230 Volt socket (Figures 5 and 6).
5. Plug in again with arrow on plug pointing to 115
Volts.
6. Change is complete.
GROUNDING THE MOTOR
Ground the pump permanently using a wire of size and
type specified by local or National Electrical Code.
1. Connect ground wire first. Connect the ground first,
then to green grounding terminal provided under
motor canopy (see Figure 5) identified as GRD. Make
ground connection to this terminal. Do not connect
motor to electrical power supply until unit is perma-
nently grounded; otherwise serious or fatal electrical
shock hazard may be caused.
2. For best ground connection, connect to a grounded
lead in the service panel or to a metal underground
water pipe or well casing at least 10 ft. long. If plastic
pipe or insulated fittings are used, run ground wire
directly to the metal well casing or use ground elec-
trode furnished by the power company.
TABLE II - RECOMMENDED FUSING AND WIRING
Branch
Max. Fuse
Wire Length
Motor Volts/ Load Rating 0’-50’ 51-100’ 101-200’ 201-300’
H.P. Phase Amps Amps AWG Wire Size
1/2 115/230/1 12.4/ 6.2 20/15 12/14 12/14 10/14 8/14
3/4 115/230/1 14.8/7.4 20/15 12/14 12/14 8/14 6/14
1 115/230/1 19.2/9.6 25/15 10/14 10/14 8/14 6/12
