DEAN MILLIVOLT GAS FRYERS
CHAPTER 2: PARTS LIST
2-17
2.5.1 Oil Drain Manifold, Drain Flush and Drain Valve Components (cont.)
ITEM PART # COMPONENT
1 823-3565 Elbow, with Bracket (LH)- 1-¼"- UFF 50
* 823-3566 Elbow, with Bracket (RH)- 1-¼"- UFF 50
2 812-1524 Drain Pipe, Left Side (Use 823-3418 for Chili’s)
3 813-0784 Drain Pipe, Right Side 1 ½” x 6”
4 813-0829 Elbow, 1-½" NPT 75°
5 813-0748 Tee, 1-½” NPT x 1-¼" BM With Handle Bracket
6 200-1827 Drain Manifold Tube- 1-½” x 13-¼"
7 813-0659 Pipe Cap, 1-½"
8 809-0884 Nut, Slip Joint- 1-½"
* 816-0544 O-ring (Slip-Joint Nut)
9 813-0686 Bell Reducer, ½" NPT x 1-½"
10 813-0165 Elbow, Street- ½" NPT 90°
11 813-0672 Nipple, ½” NPT x 8" BM
12 810-1669 Adapter, ⅝" O.D. x ½"- Female
13 810-1069 Flex Line, ⅝" x 29-½ "
14 810-1668 Adapter, ⅝" O.D. x ½"- Male
Drain Valve Components
15 106-1401 Bracket, Microswitch (Optional On SUFF/UFF Units)
16 200-1617 Washer, Drain Valve (Use Without Microswitch)
17 210-2029 Bracket, Activator- Microswitch (Also Used On Valves Without Microswitch As A
Handle-Stop)
18 210-4727 Handle (Actuator), Drain Valve
* 823-3440 Handle, Push/Pull- Drain (With Cap)
* 809-0885 Washer, ⅜” x 1” x .083"
* 809-0843 Pin, Cotter
* 816-0547 Cap, Vinyl-Red
19 807-2104 Microswitch (Optional On SUFF/UFF Units)
20 809-0842 Nut, Nylock- #4-40 (Microswitch To Bracket)
21 816-0220 Insulation, Microswitch
22 200-1257 Retainer, Nut
23 810-2127 Drain Valve, 1-½" Full Port (With Washers & Nut)
24 810-2052 Drain Valve, 1-¼" (1" Standard Port)
* 810-2442 Handle, Valve Lever
* 810-1338 Drain Valve, 1" SM20G, SR42G see note below
* 210-3902 Handle, Valve Lever (For 810-1338 Only)- SM20G
* 106-1417SP Drain Valve Assembly 1” RH and LH
* 813-0138 Nipple, 1" NPT x Close (To Adapt To 1-¼" Extended Drain Nipple)
* 813-0716 Bushing, 1" NPT x 1-¼" BM (To Adapt To 1-¼" Extended Drain Nipple)
* 813-0406 Coupling, 1-¼" NPT x 2" (To Adapt To 1-¼" Extended Drain Nipple)
25 810-2126 Drain Valve, 1-¼" Full-Port (Use 106-2439 for Assembly)
* 812-1226SP Nipple, Drain- 1-¼" Painted- SM Series Fryers (use 813-0276 for SM20)
* 813-0392 Nipple, Drain- 1-¼” NPT x 8" BM- All SR Series Fryers except SR42 w/ 1”
* 812-1681 Nipple, Drain- 1-¼” x 5” NPT
* 813-0870 Nipple, Drain- 1-¼” x 10” NPT
* 813-0669 Nipple, Drain- 1” x 8” (Use 812-1668 for 5”-SR42) (Use 813-0605 for 9”- SR62)
* Not Illustrated
Note: In Mar. 2003 SR42G went to 1” drain valves.
