4800
Four Indoor/Outdoor Wired Analog
Color Camera Recording System
8800
Eight Indoor/Outdoor Wired Analog
Color Camera Recording System
• Web-ready & mobile phone compatible DVR
system – H.264 video quality
• 320 GB media data storage (Can add up to 1TB additional hard drive)
• Indoor/outdoor night vision color cameras (IP65 rating)
• Passive IR motion detection
• 400 TV lines for clear resolution
Includes:
DVR System, Cameras (4: SKU# 4800 or 8: SKU# 8800), remote control, USB mouse,
60 ft. BNC AV cable per camera, Power Supplies (cameras and DVR), Splitter Cable,
Camera Mounting Hardware, Installation CD and Manual.
advanced
video
mobile phone/
web ready
320 GB
DVR
night vision
WIRED RECORDING KITS
Four Cameras Included
Eight Cameras Included
Back Panel Connections/Ports:
4 BNC in, 4 Audio in, 1 Audio out, 1 USB port, 1USB
Mouse, 1 BNC Main out, LAN port, DC power, RS485/
RS422 Alarm in, Alarm out and PTZ connections.
Indoor/Outdoor Wired Analog
Color Camera Recording Systems
Back Panel Connections/Ports:
8 BNC in, 1 VGA out, 1 VGA Audio in, 1 USB port, 1USB
Mouse, 1 BNC Main out, LAN port, DC power, RS485/
RS422 Alarm in, Alarm out and PTZ connections.
WIRED SURVEILLANCE
indoor/
outdoor
audio
surveillance
night vision
P-520
Indoor/Outdoor Wired Analog Color Camera
• Indoor/outdoor night vision color camera (IP44 rating)
• Built-in microphone
• 400 TV lines for clear resolution
• Compatible with other First Alert wired security systems
Includes:
1 Camera, 100 ft. BNC AV cable, Power Supply, Camera Mounting
Hardware, Manual.
P-500
Mini Indoor Wired Analog Color Camera
• Discrete placement and surveillance
• Compact size can easily be positioned anywhere
• Indoor color camera
• Built-in microphone
• 380 TV lines for clear resolution
• Compatible with other First Alert wired security systems
Includes:
1 Camera, 18 ft. AV/Power cable, Power Supply, Camera Mounting
Hardware, Manual.
discrete placement
& surveillance
audio
surveillance
Compact Size
1-1/2” high
• Solid copper conductor for less voltage drop and better signal
over longer distances - easier to handle
• Combined video and DC power in one cable
• Double shielded with aluminum foil insulation and braiding
• BNC Male connections on video cable and 1 jack male, 1
plug female on DC power cable (2.1mm I.D./5.5mm O.D.)
• 50’ (BNC-50), 100’ (BNC-100) and 300’ (BNC-3-00) lengths
Notes:
BNC-50: 50’ cable, BNC-100: 100’ cable, BNC-300: 300’ cable, .
BNC-50, BNC-100, BNC-300
RG59 COAX VIDEO & DC POWER CABLES
BNC-100F
RG59 FIRE RATED COAX VIDEO & DC POWER CABLE
Same features as above plus:
• FT-4/CMR UL approved for in-wall installations
• 100’ length
Tip:
Need longer r
uns?
Upgrade to RG59 CO
AX
cable for a better signal
over longer distances
Available
