1 2 1 2 1 2 1 2 1 2 1 3 1 3 1 3 1 3 1 3
Firestone’s Loadshare TM air helper springs improve the
ride quality on both conventional and cabover trucks.
Ideal for use on refuse compactors, utility trucks,
snowplows, buses, concrete mixers, dump trucks and
trucks equipped with lift axles. Or just about any truck
that has constantly changing loads that effect the front
end of the vehicle.
Universal mounting kits are used to install Loadshare
air helper springs on most class 6, 7 and 8 front
suspensions. Adaptations may be required due to
various engine and driveline combinations. Designed
for straight chassis and highway trucks, including:
Kenworth Ford
Mack Volvo White GMC
Navistar Western Star
Freightliner
Loadshare
®
air helper springs
Install Loadshare
TM
air helper springs:
Reduces leaf spring fatigue and tire wear.
Installs quickly on your current suspension.
Maintains proper ride height.
Reduces front end dive while braking.
Improve ride quality.
Reduce the chance of cargo damage.
Loadshare Requirements:
A 5-1/4” clearance radius (measured from spring pack
center bolt) is required for all Loadshare air helper
springs. When installing Loadshare air helper springs
make certain that steering arms, shock absorbers,
brackets, oil filters, etc., do not intrude into this area.
The Loadshare kit is intended for use on primary front
suspensions which have 3-1/2” or 4” leaf spring widths.
Basic Kit:
Each Loadshare kit comes with: two air helper springs,
mounting hardware, airline, and step by step installation
instructions. Plus, an in cab air regulator panel and gauge
that connects to your existing air supply.
Loadshare air helper springs decrease maintenance
and repair costs to both suspension and drivetrain,
keeping the truck out on the road - making money.
Loadshare
®
Applications List
Loadshare is a registered trademark of Hi-Steer of Canada
Note: Maximum inflation pressure will vary depending on load, pitch and wire diameter of the coil spring. See installation
instructions for minimum and maximum pressures.
Coil-Rite air helper springs are designed to keep your vehicle level or maintain the original ride height of the vehicle.
Do NOT exceed the vehicle’s Recommended Gross Vehicle Weight Rating (GVWR)
Footnote Chart
Notice: Firestone has made every attempt to assure that the air helper spring kits listed will properly fit. Chassis modifications made by others that effect suspension dimensions
may not provide conditions for proper fit. Due to new model introductions and manufacturer changes, Firestone reserves the right to make changes to the list without notification.
Note: Some vehicle manufacturers use brake proportioning valves to adjust braking force as a function of frame to axle distance. If you modify your suspension it effects the function
of this valve. We suggest that you check with your dealer on proper treatment of this device prior to installation of the air helper spring kits.
Coil-Rite
®
Passenger Car / Mini Van Applications List
(continued)
REQUIREMENTS
* Requires 7.50" of clearance between the frame and tire both single and dual rear wheels.
**
Requires 3.00" of clearance between the frame and tire.
*** Requires 9.50" of clearance between the frame and tire.
+ Requires 8.00" of clearance between the frame and tire.
++ Requires 6.25" of clearance between the frame and tire.
+++ Requires 6.50" of clearance between the frame and tire.
PASSENGER CARS & MINI VANS
OLDSMOBILE (continued)
MODEL YEAR VEHICLE/CHASSIS
FRONT /
REAR
AIR SPRING
REPLACEMENT
KIT PART
NUMBER
ACHIEVA 92-98 REAR 6012 4104
CUTLASS CALAIS 85-91 Front Wheel Drive REAR 6012 4104
CUTLASS, CUTLASS SUP., CALAIS 73-87 (excluding SW) REAR 6008 4114
CUTLASS, F-85, 442 67-72 (excluding SW) REAR 6007 4113
CUTLASS, VISTA CRUISER 64-66 (including SW) REAR 6009 4115
FIRENZA 82-88 Front Wheel Drive (including SW) REAR 6012 4104
SILHOUETTE 90-96 REAR 6014 4110
PLYMOUTH
RELIANT 81-94 REAR 6013 4105
SUNDANCE 87-93 REAR 6013 4105
ACCLAIM 89-95 REAR 6013 4105
PONTIAC
PHOENIX 80-84 REAR 6014 4103
PONTIAC 6000 82-91 REAR 6014 4103
FIREBIRD 82-01 Formula, Trans AM, Trans AM GTA REAR 6014 4103
J-2000, SUNBIRD 82-94 (including SW) REAR 6012 4104
GRAND AM 85-99 REAR 6012 4104
Le MANS 88-92 REAR 6012 4104
BONNEVILLE 87-99 Front Wheel Drive REAR 6021 4107
GRAND PRIX 69-72 REAR 6007 4113
GRAND PRIX 73-87 REAR 6008 4114
GRAND AM, GRAND Le MANS,
Le MANS
73-82 (including SW) REAR 6008 4114
Le MANS, CUSTOM, 'S', JUDGE,
TEMPEST, GTO GT37
67-72 (except SW) REAR 6008 4114
TEMPEST, GTO 64-66
(including SW)
REAR 6009 4115
TRANSPORT 90-96 REAR 6014 4110
SAFARI 87-89 Station Wagon REAR 6010 4116
TOYOTA
ECHO 01 REAR 6018 4118
