Data Sheet
Issue: August 2005
AMILO L1310G
Page 2 / 3
All rights, including rights created by patent grant or registration of a utility model or design as well
as rights of technical modifications are reserved. Delivery subject to availability. Designations may
be trademarks, the use of which by third parties for their own purposes may violate the rights of the
trademark owners.
Copyright
Fujitsu Siemens Computers,08/2005
Published by
Fujitsu Siemens Computers
Company stamp
Operating system
Windows XP Home, Recovery CD is included
Fujitsu Siemens Computers recommends Microsoft®
Windows® XP.
Application Software
a) Works 8.0 or
b) Works 8.0 with Office Trial Student & Teacher Edition
Magix Media Suite (optional)
Sipgate (optional)
Norton Internet Security 2005 or Norman Anti-Virus
DVD Playing & Burning Software
InterVideo WinDVD
Nero burning ROM 6
Driver & Utility CD including
Drivers, Online Manual, Adobe Acrobat Reader
Quick Touch application button utility
Internet Service Providers – country specific
Manual, Safety Guide and Warranty Guide
System, processor, architecture
Chipset: ATi RC410MB + SB400
CPU: Intel
Celeron M processor / 400 MHz FSB Celeron
M 380 (Dothan); 1 MB 2
nd
level cache
Memory
2x 256 MB DDR 333/400 SDRAM SO-DIMM
2 memory DIMM slots 200 pin
Maximum memory size: 2 GB
(no memory on board)
Storage devices / drives
HDD:
60, or 80 GB PATA IDE hard disk
ODD:
Multi format DVD burner with double layer support
CD 24x / CD-R 24x / CD-RW 20x / DVD 8x / DVD+R 8x
DVD-R 8x / DVD+RW 8x / DVD-RW 6x
DVD+R DL 4x/ DVD-R DL 4x
Display:
Crystal view
Panel size:
15.4” TFT WXGA, 1280x800 pixel
Compliance with standards
ISO 13406-2 Class II
ACPI functions
ACPI capability:
S1 LCD off
S3 save to RAM
S4 save to disk
S5 soft off
Complete boot
Graphics
ATI Radeon Xpress 200
Up to 128MB RAM shared memory
Full DirectX 9.0 Support: Vertex Shader v2.0 and Pixel
Shader v2.0 to create most realistic 3D effects
DVD quality playback
Engine Clock Scaling, Memory Clock Scaling, Core Voltage
Scaleing, Dynamic Lane Count Switching
Support ATi PowerOnDemand and PowerPlay for longer
battery life
Dual view possible under Win XP Home
Max. recommended external resolution (CRT only)
1600 x 1200 / 16M / 85Hz
I/O Interfaces
4x USB (version 2.0)
1x S-video (4 pin)
1x CRT (VESA compatible)
1x IEEE 1394
1x typ I/II PC card slot (32 bit CardBus support)
1x 4 in 1 Card reader (SD/MS/MS Pro/MMC)
1x DC-In
1x modem (56 Kbps (.V90)
1x LAN (10/100)
1x W-LAN (mini PCI, Gemtek/Ralink)
1x SPDIF shared with headphone out (stereo)
1x microphone in (mono) shared with line in
1x RJ11, 1x RJ45
Communications
§
Built-in 56K, .V92 fax modem (MDC (AC’97)
§
10/100Mpbs LAN (Broadcom BCM4401)
§
Integrated wireless LAN (IEEE 802.11 b/g) solution
-
industry standard wireless LAN security
support
-
speeds up to 54Mbps
For use in BE, CH, DK, DE, EE, FI, FR, EL, IE, IS, IT, LI,
LV, LT, LU, MT, NL, NO, PL, AT, PT, SE, SK, ES, CZ, HU,
UK, CY, NL
Audio
AC97 ALC655
2 high quality built-in speakers (1.5 W)
microphone in (mono) shared with line-in
Headphone out shared with SPDIF support
sound volume controlled by Hot Keys
Launch Keys
3 Launch Keys located on top of the keyboard enabling the
user to launch the following applications:
§
WLAN
§
Internet browser
§
Silent mode (reduce noise level / fan speed, by
reducing the CPU & VGA performance)
(Office applications, Internet and DVD playback are
not affected)
Hot Keys
The following Hot Keys or key combinations are available
Fn + F3:
LCD Ext. CRT/TV switch
Fn + F6:
speaker on/off
Fn + F8:
increase display brightness
Fn + F9:
decrease display brightness
Fn + F10:
volume down
Fn + F11:
volume up
