15
Q UAD D ISPLAY
1. Use to select Quad display ON/OFF.
2. Press to confirm the change.
3. Turn all available channels ON before changing to Quad mode.
4. To exit the Quad display, press directional keys to enter single channel:
= CAM1; = CAM2; = CAM3; = CAM4
Quad mode is recommended when the system is equipped with more than
one camera. The system will only record one channel, not the Quad display.
S CAN P ERIOD
Scan Period selects the time each camera will be displayed.
1. Use to change Scan Time interval: OFF, 5 sec, 10 sec, or 15 sec.
2. Press to confirm the change.
This function is available for multi-camera systems. Only camera of current
display can be triggered during scan time. Recommended scan time is 5 sec.
Scan Time turns off when CH+, CH-, or REC is selected for manual scan
or record.
