Page 32: L. slv
27
CONFIGURING THE
DSP8000
LOUDSPEAKERS
To specify the speaker position
• Press
A or V to specify the speaker position.
The options are shown in the following table:
Display
Position
L.
Left.
R.
Right.
C.
Centre (Type 6 only).
S.L.
Left surround (Type 6 only).
S.R.
Right surround (Type 6 only).
To choose master or slave
You should select one loudspeaker to be the master; this will normally be
the centre channel. See Setting up the DSP8000 loudspeakers, page 9. The
other DSP8000 loudspeakers should be configured as slaves as follows.
• Press the green
> (Play) key on the remote.
The display shows,
for example:
L. Slv.
When you have configured the loudspeaker:
• Switch off the DSP8000 loudspeaker, using the power switch on the
back, and then switch on again to restore normal operation.
