FEIN Power Tools ASB 647-1 User Manual
Page 3
Fein Power Tools
Asb 647-1 / Asbe 647-1 Parts List
Item
Item Number
Description
Reqd.
10
3-19-03-119-00-3
MOTOR HOUSING
1
20
3-07-12-067-01-7
BRUSH HOLDER
2
40
4-30-41-001-99-4
SCREW
4
50
3-07-11-067-00-4
CARB0N BRUSH
2
60
4-30-03-029-04-8
SCREW
2
70
3-07-19-062-01-7
CABLE
1
80
3-07-19-065-01-3
CABLE
1
90
5-1-212-002-11-1
FIELD COIL
1
110
4-30-01-002-04-0
SCREW
2
120
3-14-28-022-00-6
AIR CONDUCTING RING
1
130
3-24-27-069-00-6
COVER
1
140
4-30-46-001-00-2
SCREW
4
150
4-30-03-029-04-8
SCREW
1
210
5-3-212-002-11-3
ARMATURE
1
240
3-10-04-010-00-3
VENTALATION FAN
1
270
3-01-10-016-00-2
DRIVE SHAFT
1
280
4-26-43-009-00-5
RING
1
290
3-36-07-072-00-2
PLANETARY GEAR 41T
2
300
4-17-15-009-00-1
NEEDLE CAGE
2
310
4-17-09-006-00-0
ROLLER
2
320
4-17-08-014-00-1
BALL
24
330
3-26-02-045-00-0
THRUST COLLAR
1
340
3-09-01-231-00-5
COMPRESSION SPRING
1
350
3-01-12-023-00-9
PERCUSSION PISTON
1
360
4-17-08-025-00-4
BALL
2
370
3-15-08-124-01-3
FRONT HOUSING
1
380
3-21-31-037-00-5
LUBRICATING NIPPLE
1
390
3-01-04-047-00-5
TOOL HOLDER
1
400
3-15-06-195-01-2
INTER BEARING
1
430
3-07-05-035-01-3
CABLE
1
440
3-14-13-090-00-3
CABLE PROTECTING SLEEVE
1
450
3-12-04-090-00-3
HANDLE-LOWER PART
1
460
3-12-04-091-00-2
HANDLE-UPPER PART
1
470
3-07-01-068-00-3
REVERSING SWITCH
1
480
3-07-22-074-00-9
CAPACITOR
1
490
3-24-31-021-00-7
CABLE CLAMP
1
500
4-30-41-011-99-3
SCREW
2
510
4-30-41-023-04-6
SCREW
2
520
3-14-15-023-00-4
RUBBER BUFFER (ASBE 647-1)
1
530
4-17-01-204-13-1
BALL BEARING
1
540
4-30-33-005-04-7
SCREW
4
550
4-30-33-016-05-5
SCREW
4
560
4-30-14-042-05-3
SCREW
4
570
4-24-43-003-04-3
LOCK WASHER
4
580
4-24-43-004-05-7
LOCK WASHER
8
600
4-17-01-207-03-3
BALL BEARING
1
610
3-06-02-010-00-0
PACKING RING
1
620
3-24-22-093-00-7
COVERING PLATE
1
640
4-17-01-603-01-3
BALL BEARING
1
670
3-26-24-046-02-8
WASHER
670
3-26-24-046-03-4
WASHER
800
3-12-07-066-00-4
COVER (ASB 647-1)
1
800
3-12-07-067-00-8
COVER (ASBE 647-1)
1
805
3-07-01-085-01-5
REVERSING SWITCH (ASB 647-1)
1
805
3-07-01-085-02-1
REVERSING SWITCH (ASBE 647-1)
1
830
3-07-62-016-01-0
SPEED CONTROL (ASBE 647-1)
1
840
3-28-05-061-00-6
SWITCH GRIP (ASBE 647-1)
1
850
4-17-08-018-00-0
BALL (ASBE 647-1)
1
860
3-09-01-003-00-0
SPRING (ASBE 647-1)
1
870
3-24-22-095-00-9
PLATE (ASBE 647-1)
1
