Ethernet 100 Base-TX
Autopilot Autopilot
GPS Navigator GPS Navigator
SDME SDME
F E A T U R E S o f E C D I S
ENC IHO S57 Edition 3
Optional pedestal
s The electronic chart can be overlaid with a variety of navigation data such as Radar echo
images, ship’s position, heading, speed and others to facilitate safe and efficient navigation.
s Complies with the following IMO and IEC regulations:
• IMO A.817(19) • IMO MSC.64(67) Annex 5
• IMO MSC.86(70) Annex 4 • IMO A.694(17)
• IEC 61174 edition 2 • IEC 60945 edition 4
• IEC 61162-1 edition 2 • IEC 61162-2 edition 1
s Compatible with ENC (S57 Edition 3) charts, ARCS charts and C-MAP CM93 ed3*
*available in the near future
s Flexible expandability allows the ECDIS to be networked with radar/ARPA, positioning
equipment, autopilot and others to consolidate the navigation system
s User-customizable chart drawing function
s Route planning applicable to both
Mercator’s sailing and great-circle sailing
s Track Control System when connected
with autopilot (Option)
s Navigation data for the past 12 hours
can be recorded
(The data to be recorded includes: time, ship’s position,
GPS correction data, ship’s heading, ship’s speed)
s True Motion and Relative Motion modes are
available
s Ergonomically designed control panel provides
ease-of-use
The ergonomically designed control panel consists of
a trackball, a thumbwheel and a keyboard. The logically
arranged keyboard provides intuitive operation. Optionally,
the compact control head only with a trackball and
a thumbwheel is available for space-saving installation.
s Navigation data is shared within an Ethernet network
The 100 Base-T Ethernet is utilized to link
this ECDIS with up to four sets of radar/ARPA
FAR-21x7/28x7. This link gives high-speed
navigational data sharing within the system
and allows operators to choose either a single
station system or a total Integrated Navigation
System (INS).
s High-resolution color LCD
The use of 20.1"/23.1" high-resolution SXGA/UXGA LCDs
provide crystal clear presentations of navigation
information, such as marks, lines and waypoints.
The LCDs also allows for installation where space is limited.
s Displays 200 AIS targets
When connected to an optional AIS transponder,
the FEA-2107/2807 can store up to 1,000 AIS
targets information in its storage buffer, and
displays up to 200 AIS targets within the user-
defined range on the display. This provides
operators with another solution for observation
of other craft.
s Streamlined design
The color scheme of the optional
pedestal is a stylish pearl white and
gray. The streamline design fits
perfectly in the modern bridge.
A f l e x i b l e E t h e r n e t n e t w o r k
a l l o w s f o r f u t u r e e x p a n d a b i l i t y
Palm control unit
Sleeping AIS Target Activated Target Lost Target Dangerous Target Selected Target
