www.fmiproducts.com 120926-26C 8
Figure 7 - Fireplace Settings (Default Settings are Circled)
FLAME Off Low Medium High
EMBER Off Low Medium High
HEATER Off On
CLEANING AND MAINTENANCE
WARNING: Always discon-
nect power and allow the heater
to cool before performing any
cleaning, maintenance or reloca-
tion of this heater. Turn controls
to OFF and remove plug from
outlet or turn off circuit breaker
to heater.
To service electric fireplace it may be neces-
sary to remove it from the mantel or enclosure
in which it is installed. Let unit cool completely
before cleaning or servicing.
CLEANING FIREBOx
1. Open control panel door by pressing on
right side. A spring magnet will push door
forward. Pull door down to open.
2. Remove 2 screws holding front trim in
place. Pull gently to remove trim (see
Figure 8). There are magnets on the lower
portion of trim (see Figure 8)
3. With gloves and safety glasses in place,
remove 4 screws from glass retainer
brackets (2 per bracket).
4. Carefully remove front glass and brackets
(see Figure 9).
5. Using a brush vacuum attachment, gently
clean compartment.
6. After cleaning compartment, replace front
glass, screw, bracket and trim.
Figure 9 - Removing Brackets and Front
Glass
Bracket
Front Glass
Figure 8 - Removing Trim
Magnets on
Back of Trim
Screws
Bracket
Screws
Trim
Control Panel Door
OPERATION
Continued
